EPM1270F256I5N vs EPM1270F256 Comparison
Detailed side-by-side comparison of EPM1270F256I5N by Intel and EPM1270F256 by Altera. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Intel
EPM1270F256I5N - 980-Macrocell MAX II CPLD, 256-FBGA | Intel / Altera
EPM1270F256I5N β Active
Specification Comparison
| Parameter | EPM1270F256I5N | EPM1270F256 |
|---|---|---|
| Brand | Intel | Altera |
| Category | FPGA & CPLD | FPGA & CPLD |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $12.40 | $10.85 |
| Family | MAX II | MAX II |
| Device Type | CPLD - Complex Programmable Logic Device | β |
| Macro Cells | 980 | β |
| Logic Elements | 1270 | 1270 |
| User I/O Pins (max) | 212 | β |
| User Flash Memory | 8 Kbits | 8 Kbits |
| Package / Case | 256-FBGA (FineLine BGA, 17x17 mm) | β |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature | -40C to +100C (TJ) | -40C to +100C (industrial, I5N suffix) |
| Speed Grade | I5 | β |
| Pin-to-Pin Logic Delay (tPD) | 6.2 ns | β |
| Maximum Operating Frequency (fMAX) | 201.1 MHz | β |
| Supply Voltage - Core | 1.8 V (internal, regulated) | β |
| Supply Voltage - I/O | 2.5 V / 3.3 V (MultiVolt: 1.5 V / 1.8 V / 2.5 V / 3.3 V) | β |
| Programming Interface | JTAG (IEEE 1149.1) - in-system programmable | JTAG (IEEE 1149.1) |
| Process Technology | 0.18 um Flash-based CMOS | 0.18 Β΅m |
| RoHS Status | Compliant | Compliant |
| Halogen Free | Compliant | β |
| Country of Origin | Malaysia / Republic of Korea | β |
| Macro Cells (Typical) | β | 980 |
| User I/O (Max) | β | 212 |
| Supply Voltage (Core) | β | 2.5 V / 3.3 V (on-chip regulator) |
| I/O Voltages Supported | β | 1.5 V / 1.8 V / 2.5 V / 3.3 V (MultiVolt) |
| Maximum Frequency | β | 201.1 MHz |
| Package | β | 256-Pin FineLine BGA |
| Configuration Memory | β | Non-volatile flash (instant-on) |
| Vertical Migration | β | Pin-compatible with EPM570F256 and EPM2210F256 |
