AD8310ARM - 95dB Log Amp DC-440MHz | Analog Devices
MPN: AD8310ARM β Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $6.51 | $6.51 |
| 10 | $5.98 | $59.80 |
| 100 | $5.21 | $521.00 |
| 500 | $4.56 | $2,280.00 |
| 1,000 | $4.1 | $4,100.00 |
Drop-in alternatives for AD8310ARM β same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool β Select alternative parts for side-by-side comparison:
AD8310ARMZ
β Drop-Inβ In Stock
$4.39 / Unit
View Datasheet βAD8314ARMZ
β Drop-Inπ Reference alternative (not in catalog)
MAX4000
β Drop-Inπ Reference alternative (not in catalog)
LT5534
β Drop-Inπ Reference alternative (not in catalog)
AD8310ARM Maximum Ratings & Electrical Characteristics
| Function | Demodulating Logarithmic Amplifier |
| Frequency Range | DC to 440 MHz |
| Dynamic Range | 95 dB |
| Input Range | -91 dBV to +4 dBV |
| Logarithmic Slope | 24 mV/dB |
| Logarithmic Intercept | -95 dBV |
| Linearity | Β±0.4 dB |
| Rise Time | <15 ns |
| Output Current Capability | 25 mA into grounded load |
| Supply Voltage Range | 2.7 V to 5.5 V |
| Quiescent Current | 8 mA typical |
| Package | 8-Lead MSOP |
| Operating Temperature Range | -40Β°C to +85Β°C |
| RoHS Compliance | Compliant (AD8310ARMZ) |
| Mounting Type | Surface Mount |
AD8310ARM Pin Configuration
| Pin 1 | INP β Non-inverting input |
| Pin 2 | INM β Inverting input |
| Pin 3 | GND β Ground |
| Pin 4 | OUT β Logarithmic output |
| Pin 5 | VPS β Positive supply |
| Pin 6 | NC β No connect |
| Pin 7 | NC β No connect |
| Pin 8 | NC β No connect |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this component. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
AD8310ARM is suitable for 6 applications: RF Power Measurement, Received Signal Strength Indication (RSSI), Radar and Communication Systems, Test and Measurement Equipment, Wireless Infrastructure, Portable and Battery-Powered Devices.
RF Power Measurement
The AD8310ARM is ideal for RF power measurement due to its 95 dB dynamic range and DC to 440 MHz frequency coverage. It converts RF signal levels to a DC voltage proportional to the log of the input power, enabling accurate power monitoring in transmitters and receivers. Its fast rise time (<15 ns) allows real-time power level detection in burst signals. The device's high output current (25 mA) can directly drive ADC inputs or display circuits without buffering. In this application, the AD8310ARM is typically placed after a directional coupler or attenuator to sample the RF signal. Its logarithmic response provides a wide measurement range without switching gain stages, simplifying calibration. The low supply current (8 mA) makes it suitable for portable power meters.
Recommended
Received Signal Strength Indication (RSSI)
The AD8310ARM is specifically designed for RSSI in communication receivers. Its 95 dB dynamic range allows accurate signal strength measurement from weak to strong signals, essential for automatic gain control (AGC) and signal monitoring. The device's fast response time (<15 ns) enables rapid AGC loop settling. The output voltage, proportional to the log of the input, can be directly digitized by an ADC for digital RSSI processing. In cellular base stations and wireless infrastructure, the AD8310ARM provides reliable signal level detection across a wide frequency range (DC to 440 MHz). Its small MSOP package and low power consumption make it suitable for multi-channel receivers. The device's high output current capability allows direct driving of comparators or ADC inputs without additional buffering.
Recommended
Radar and Communication Systems
In radar and communication systems, the AD8310ARM is used for signal level detection and gain control. Its wide dynamic range (95 dB) and frequency range (DC to 440 MHz) cover IF and RF stages. The fast rise time (<15 ns) is critical for pulse radar applications where signal levels change rapidly. The device's logarithmic output simplifies the design of AGC loops, as the control voltage is directly proportional to the input level in dB. The AD8310ARM can be used in both transmit and receive paths for power monitoring and fault detection. Its low power consumption and small footprint are advantageous in phased-array and portable systems. The device's high output current (25 mA) allows direct driving of display or control circuits.
Recommended
Test and Measurement Equipment
The AD8310ARM is widely used in test and measurement equipment such as spectrum analyzers, power meters, and signal generators. Its accurate logarithmic response (linearity Β±0.4 dB) ensures precise signal level measurements. The wide frequency range (DC to 440 MHz) allows it to be used in various test setups. The fast rise time (<15 ns) enables measurement of pulsed signals. The device's high output current (25 mA) can drive meters or ADCs directly. In power meters, the AD8310ARM provides a linear-in-dB output that simplifies calibration. Its low power consumption is beneficial for portable test instruments. The small MSOP package allows high-density designs in multi-channel test equipment.
Recommended
Wireless Infrastructure
In wireless infrastructure, the AD8310ARM is used for power monitoring and AGC in base stations and repeaters. Its 95 dB dynamic range covers the wide signal variations encountered in cellular systems. The device's frequency range (DC to 440 MHz) is suitable for IF and RF stages. The fast response time (<15 ns) enables rapid AGC adjustments. The logarithmic output simplifies the interface to digital control loops. The AD8310ARM's low power consumption is important for remote radio heads where power efficiency is critical. Its small package allows integration into compact RF modules. The high output current (25 mA) can drive external circuitry without additional buffers.
Recommended
Portable and Battery-Powered Devices
The AD8310ARM is suitable for portable and battery-powered devices due to its low supply current (8 mA) and small MSOP package. It is used in handheld spectrum analyzers, field strength meters, and portable communication devices. The wide dynamic range (95 dB) allows accurate signal measurement without external gain switching. The device operates from a single 2.7 V to 5.5 V supply, compatible with battery voltages. Its fast response time (<15 ns) is useful for burst signal detection. The high output current (25 mA) can drive low-power displays or ADCs. The AD8310ARM's logarithmic output simplifies signal level indication in portable instruments.
Recommended
Recommended Products Summary
Engineering reference data for AD8310ARM β comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | AD8310ARMZ | AD8314ARMZ | MAX4000 | LT5534 |
|---|---|---|---|---|---|
| Package | 8-Lead MSOP | 8-Lead MSOP | 8-Lead MSOP | 8-Lead MSOP | 8-Lead MSOP |
| Brand | Analog Devices | Analog Devices | Analog Devices | Maxim Integrated | Analog Devices |
| Dynamic Range | 95 dB | 95 dB | 45 dB | 45 dB | 60 dB |
| Frequency Range | DC to 440 MHz | DC to 440 MHz | DC to 100 MHz | DC to 500 MHz | DC to 3 GHz |
| Supply Voltage | 2.7 V to 5.5 V | 2.7 V to 5.5 V | 2.7 V to 5.5 V | 2.7 V to 5.5 V | 2.7 V to 5.25 V |
| Quiescent Current | 8 mA | 8 mA | 5.5 mA | 5.9 mA | 7 mA |
| Rise Time | <15 ns | <15 ns | [DATA_NEEDED] | [DATA_NEEDED] | [DATA_NEEDED] |
| RoHS Compliant | No (AD8310ARM), Yes (AD8310ARMZ) | Yes | Yes | Yes | Yes |
Key Differentiators
- Wider dynamic range (95 dB) compared to AD8314ARMZ (45 dB) (vs AD8314ARMZ)
- Faster rise time (<15 ns) compared to typical log amps (vs AD8314ARMZ)
- Higher output current capability (25 mA) compared to MAX4000 (vs MAX4000)
Design Notes
The AD8310ARM operates from a single 2.7 V to 5.5 V supply. Use a low-ESR 0.1 Β΅F ceramic capacitor in parallel with a 1 Β΅F capacitor placed as close as possible to the VPS pin to ensure stable operation. The typical quiescent current is 8 mA, so power dissipation is minimal, but ensure the supply can handle transient currents during output swings.
For optimal performance, keep the input traces short and shielded to minimize parasitic capacitance and noise pickup. The input is high impedance, so route it away from high-frequency digital signals. Use a ground plane under the device to provide a low-impedance return path. Place decoupling capacitors close to the supply pins.
Do not exceed the absolute maximum supply voltage of 5.5 V. The input signal should be kept within the specified dynamic range (-91 dBV to +4 dBV) to avoid saturation. If the input has a DC offset, use AC coupling. The output can drive capacitive loads up to 50 pF; for larger loads, add a buffer.
Compliance Information
The AD8310ARM (non-Z) is not RoHS compliant. The AD8310ARMZ version is RoHS compliant. REACH and conflict minerals status not specified in the provided data.
