EP2S15F484C4 vs EP2S15F484I4 Comparison
Detailed side-by-side comparison of EP2S15F484C4 by Intel and EP2S15F484I4 by Altera. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Altera
EP2S15F484I4
EP2S15F484I4 - Stratix II FPGA, 15K LE, 484-FBGA, Industrial | Altera
EP2S15F484I4 β Last Time BuySpecification Comparison
| Parameter | EP2S15F484C4 | EP2S15F484I4 |
|---|---|---|
| Brand | Intel | Altera |
| Category | FPGA & CPLD | FPGA & CPLD |
| Lifecycle Status | Last_time_buy | Last_time_buy |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $205.00 | $253.03 |
| Family | Stratix II | Stratix II |
| Logic Elements (LEs) | 15,600 | β |
| Adaptive Logic Modules (ALMs) / CLBs | 6,240 | β |
| Embedded Memory (Bits) | 419,328 | β |
| Maximum User I/O | 342 | 342 |
| DSP Blocks | Yes (integrated multiplier-accumulators) | Yes (12 dedicated 18x18 multipliers) |
| Package | 484-FBGA (FBGA-484) | 484-ball FBGA (FineLine BGA) |
| Package Dimensions | 23 mm x 23 mm | β |
| Ball Pitch | 1.0 mm | β |
| Process Technology | 90 nm CMOS | 90 nm |
| Core Performance | Up to 717 MHz | β |
| Speed Grade | C4 (-4, mid-tier) | β |
| Temperature Grade | Commercial (C): 0 C to +85 C junction | β |
| Supply Voltage (Core) | [DATA_NEEDED: VCCINT nominal] | β |
| I/O Standards Supported | LVDS, LVTTL, LVCMOS, SSTL, HSTL | β |
| External Memory Interface | DDR, DDR2, QDR SRAM | β |
| Configuration Method | Serial/parallel, JTAG | β |
| RoHS Status | Compliant (lead-free FBGA package) | [DATA_NEEDED: RoHS status] |
| Logic Elements | β | 15,600 |
| Adaptive Logic Modules (ALMs) | β | 6,240 |
| Embedded Memory (bits) | β | 419,328 |
| Embedded Memory Blocks | β | TriMatrix (MLAB, M512, M4K) |
| Transceiver Channels | β | Up to 12 (multi-gigabit) |
| Core Voltage (VCCINT) | β | 1.2 V |
| Operating Temperature Grade | β | Industrial (I4) |
| Mounting Type | β | Surface Mount |
| Configuration Scheme | β | FPGA - SRAM-based |
