EP4CE6E22C8LN vs EP4CE10E22C8N Comparison
Detailed side-by-side comparison of EP4CE6E22C8LN by Intel and EP4CE10E22C8N by Intel. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Intel
EP4CE6E22C8LN
EP4CE6E22C8LN - Cyclone IV E FPGA, 6K LE, EQFP-144 | Intel
EP4CE6E22C8LN β Active
Specification Comparison
| Parameter | EP4CE6E22C8LN | EP4CE10E22C8N |
|---|---|---|
| Brand | Intel | Intel |
| Category | FPGA & CPLD | FPGA & CPLD |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $28.66 | $11.10 |
| Series | Cyclone IV E | Cyclone IV E |
| Device Family | EP4CE6 | β |
| Logic Elements (LE) | 6,272 | 10,320 |
| Configurable Logic Blocks (CLBs) | 392 | β |
| Embedded Memory | 276,480 bits | β |
| M9K Memory Blocks | 30 | β |
| Embedded 18x18 Multipliers | 15 | β |
| PLLs | 2 | β |
| Maximum User I/O | 91 | 91 |
| Package | EQFP-144 (PQFP144, 22x22 mm, 0.5 mm pitch, exposed pad) | 144-LQFP Exposed Pad (E22) |
| Core Supply Voltage | 1.2 V | β |
| Speed Grade | -8 (commercial) | 8 |
| Operating Temperature | 0C to +85C (commercial) | 0C to +85C |
| RoHS Status | Lead-free (compliant) | Compliant |
| Mounting Type | Surface Mount | Surface Mount |
| Family | β | EP4CE10 |
| Embedded Memory (M9K blocks) | β | 46 |
| Embedded Memory (total) | β | 414 Kbit |
| Number of Pins | β | 144 |
| Temperature Grade | β | Commercial (C) |
| Process Technology | β | 60 nm low-power |
| PLL Count | β | 2 |
| Configuration Mode | β | JTAG / AS / AP / PS |
| Supply Voltage (Core) | β | 1.0 V to 1.2 V |
| Lead-Free | β | Yes |
