EPC1LLC20 vs EPC1LI20N Comparison
Detailed side-by-side comparison of EPC1LLC20 by Intel and EPC1LI20N by Altera. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Intel
EPC1LLC20
EPC1LLC20 - 1Mb Serial Config Memory | Intel (Altera) | 20-Pin PLCC
EPC1LLC20 Obsolete
Specification Comparison
| Parameter | EPC1LLC20 | EPC1LI20N |
|---|---|---|
| Brand | Intel | Altera |
| Category | Memory ICs | Memory ICs |
| Lifecycle Status | Obsolete | Last_time_buy |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $9.95 | $7.80 |
| Memory Type | Serial Configuration Flash | OTP Configuration PROM (One-Time Programmable) |
| Memory Size | 1 Mbit (1,048,576 bits) | 1 Mbit (1,048,576 bits) |
| Interface | Altera Serial Configuration (4-wire) | β |
| Serial Clock Frequency | 8 MHz maximum | β |
| Supply Voltage (VCC) | 2.7 V to 3.6 V (3.3 V typical) | β |
| Package | 20-pin PLCC (LLC) | β |
| Programming Cycles Endurance | 100,000 cycles minimum | β |
| Data Retention | 20 years minimum | β |
| Operating Temperature | [DATA_NEEDED: operating temperature range] | -40C to +85C (Industrial) |
| Programming Mode | In-system via serial interface | β |
| Configuration Compatibility | Altera FLEX, ACEX, APEX, Cyclone, Mercury | β |
| Mounting Type | Surface Mount (PLCC socket or solder) | Surface Mount (PLCC socket or solder) |
| Lead-Free / RoHS | [DATA_NEEDED: RoHS compliance status] | β |
| MSL Level | [DATA_NEEDED: MSL moisture sensitivity level] | β |
| Standby Current | [DATA_NEEDED: standby current] | β |
| Interface Type | β | Serial (Altera proprietary configuration protocol) |
| Package / Case | β | 20-LCC (J-Lead), PLCC-20 |
| Package Dimensions | β | 9 mm x 9 mm (PLCC-20 J-lead) |
| Supply Voltage - VCCINT | β | 3.0 V to 3.6 V |
| Supply Voltage - VCCIO | β | 4.5 V to 5.5 V |
| JTAG / Boundary Scan | β | IEEE 1149.1 compliant (for programming) |
| Programmable Compression | β | Yes (reduces bitstream 30-55%) |
| Packaging | β | Tube |
| Lead Finish | β | Matte Sn (per JEDEC J-STD-020) |
| RoHS Status | β | Compliant |
| Target FPGA Families | β | Cyclone, FLEX 10K, APEX, ACEX 1K (LUT-based) |
