TLE9104SHXUMA1 vs BTS462TATMA1 Comparison
Detailed side-by-side comparison of TLE9104SHXUMA1 by Infineon and BTS462TATMA1 by Infineon. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Infineon
TLE9104SHXUMA1
TLE9104SHXUMA1 - 4-Ch 3A SPI Low-Side Switch | Infineon
TLE9104SHXUMA1 β Active
Specification Comparison
| Parameter | TLE9104SHXUMA1 | BTS462TATMA1 |
|---|---|---|
| Brand | Infineon | Infineon |
| Category | Power MOSFET Drivers | Power MOSFET Drivers |
| Lifecycle Status | Active | Active |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $3.72 | $1.38 |
| Product Type | Multi-Channel Low-Side Power Switch | Smart High-Side Power Switch |
| Number of Channels | 4 | 1 |
| Load Current per Channel | 3 A (continuous) | β |
| Topology | 1:1 N-Channel Low-Side Switch | β |
| Supply Voltage Range (VDD) | 4.5 V to 28 V | β |
| Logic Reference (VIO) | 3.3 V / 5 V compatible | β |
| Communication Interface | 16-bit SPI | β |
| R_DS(on) per Channel | [DATA_NEEDED: typical R_DS(on) in mohm] | β |
| Operating Temperature | -40 Β°C to +150 Β°C (junction) | -40 C to +150 C (junction) |
| Package | PG-DSO-20-88 (20-pin BFSOP with exposed pad) | PG-TO252-5 (DPAK-5) |
| Mounting Type | Surface Mount | Surface Mount |
| Protection Features | Over-current, Over-temperature, Over-load, short-to-ground, open-load detection | β |
| Diagnostic Output | SPI status registers (per-channel fault flags) | β |
| Automotive Qualification | AEC-Q100 qualified (automotive grade) | β |
| MSL Level | MSL3 (per JEDEC J-STD-020) | [DATA_NEEDED: MSL rating] |
| RoHS / Lead-Free | RoHS compliant, lead-free | β |
| Reset Pin (RESN) | Active-low with configurable reset duration | β |
| Manufacturer | β | Infineon Technologies |
| Output Configuration | β | High-Side |
| Output Current (Continuous) | β | 3.5 A |
| On-State Resistance (RDS(on)) | β | [DATA_NEEDED: typical RDS(on) in mOhm] |
| Supply Voltage Range (Vbb) | β | 5 V to 34 V |
| Load Dump Protection | β | Yes |
| Overvoltage Protection | β | Yes |
| Overload / Current Limit | β | Yes |
| Short-Circuit Protection | β | Yes |
| Thermal Shutdown | β | Yes (with auto-restart) |
| Undervoltage Shutdown | β | Yes |
| Fast Demagnetization | β | Yes (for inductive loads) |
| Diagnostic Output (STATUS pin) | β | Yes |
| RoHS Status | β | Compliant |
