EP2C8AF256I8N vs EP2C8F256CX1VAA Comparison
Detailed side-by-side comparison of EP2C8AF256I8N by Intel and EP2C8F256CX1VAA by Altera. Compare key specifications, electrical parameters, packaging, lifecycle status, pricing, and availability to determine the best component for your design requirements.
Specification Comparison
| Parameter | EP2C8AF256I8N | EP2C8F256CX1VAA |
|---|---|---|
| Brand | Intel | Altera |
| Category | FPGA & CPLD | FPGA & CPLD |
| Lifecycle Status | Nrnd | Obsolete |
| Stock Status | In Stock | In Stock |
| Unit Price (USD) | $21.40 | $56.80 |
| Family | Cyclone II | Cyclone II |
| Logic Elements (LE) | 8,256 | β |
| Embedded Memory Bits | 165,888 bits (162 Kbit RAM) | β |
| Embedded Multipliers (18x18) | 36 | 18 |
| Maximum User I/O Pins | 182 | 182 |
| PLLs | 4 | 2 |
| Global Clocks | 16 | β |
| Configuration Elements | Embedded SRAM, JTAG, AS, PS | β |
| Core Voltage (VCCINT) | 1.2 V | 1.15 V to 1.25 V (typ 1.2 V) |
| I/O Voltage (VCCIO) | 1.5 V / 1.8 V / 2.5 V / 3.3 V (bank-selectable) | 1.2 V to 3.3 V (bank-dependent) |
| Process Technology | 90 nm CMOS, SRAM-based | 90 nm low-k CMOS |
| Package | 256-ball FBGA (FineLine BGA) | 256-ball FBGA (FineLine BGA) |
| Operating Temperature | -40C to +100C (Industrial, I suffix) | β |
| Mounting Type | Surface Mount (BGA) | β |
| RoHS Status | Lead-free (per Altera ordering code suffix) | Compliant (lead-free) |
| Speed Grade | 8 | C8 |
| Status Suffix | N (lead-free, Pb-free) | β |
| Logic Elements | β | 8,256 |
| Total Memory Bits | β | 162,000 (36 M4K blocks) |
| Global Clock Networks | β | 8 |
| User I/O Banks | β | 8 |
| Operating Temperature Range | β | -40C to +85C (industrial, VAA suffix) |
| Configuration Modes | β | Passive Serial, Active Serial, JTAG |
