IS43TR16256AL-107MBL - 4Gb DDR3L SDRAM 256Mx16 | ISSI
MPN: IS43TR16256AL-107MBL ✓ Active| Qty | Unit Price | Extended |
|---|---|---|
| 1 | $8.5 | $8.50 |
| 10 | $7.8 | $78.00 |
| 100 | $7.1 | $710.00 |
| 500 | $6.5 | $3,250.00 |
| 1,000 | $6 | $6,000.00 |
Drop-in alternatives for IS43TR16256AL-107MBL — same package, pin-to-pin compatible. Different-package parts requiring PCB rework are excluded.
Quick Comparison Tool — Select alternative parts for side-by-side comparison:
IS43TR16256AL-107MBLI
✅ Drop-In✓ In Stock
$2 / Unit
View Datasheet →IS43TR16256BL-107MBL
✅ Drop-In📋 Reference alternative (not in catalog)
IS43TR16256AL-125KBL
✅ Drop-In✓ In Stock
$5.6 / Unit
View Datasheet →IS43TR16256AL-107MBLI-TR
✅ Drop-In✓ In Stock
$5.6 / Unit
View Datasheet →MT41K256M16HA-107G:E
✅ Drop-In✓ In Stock
$4 / Unit
View Datasheet →K4B4G1646E-BYMATCV
✅ Drop-In✓ In Stock
$5.9 / Unit
View Datasheet →H5TC4G63AFR-PBR
✅ Drop-In✓ In Stock
$5.9091 / Unit
View Datasheet →IS43TR16256AL-107MBL Maximum Ratings & Electrical Characteristics
| Memory Type | DDR3L SDRAM |
| Memory Size | 4 Gbit |
| Organization | 256M x 16 |
| Supply Voltage | 1.35 V |
| Data Rate | 1866 MT/s |
| Clock Frequency | 933 MHz |
| Access Time | 20 ns |
| CAS Latency | 13 |
| Interface | Parallel |
| Package | 96-TWBGA (9x13 mm) |
| Operating Temperature | 0°C to +95°C (case) |
| Mounting Type | Surface Mount |
| RoHS Status | Compliant |
| Burst Length | 8 and 4 (with burst chop) |
| On-Die Termination | Yes (ODT) |
IS43TR16256AL-107MBL Pin Configuration
| Pin A1 | VDD — Power supply (1.35V) |
| Pin A2 | DQ0 — Data input/output 0 |
| Pin A3 | DQ1 — Data input/output 1 |
| Pin B1 | VSS — Ground |
| Pin B2 | DQ2 — Data input/output 2 |
| Pin B3 | DQ3 — Data input/output 3 |
| Pin C1 | VDDQ — DQ power supply |
| Pin C2 | DQ4 — Data input/output 4 |
| Pin C3 | DQ5 — Data input/output 5 |
| Pin D1 | VSSQ — DQ ground |
| Pin D2 | DQ6 — Data input/output 6 |
| Pin D3 | DQ7 — Data input/output 7 |
| Pin E1 | CK — Clock input |
| Pin E2 | CK# — Complementary clock input |
| Pin E3 | CKE — Clock enable |
| Pin F1 | CS# — Chip select |
| Pin F2 | RAS# — Row address strobe |
| Pin F3 | CAS# — Column address strobe |
| Pin G1 | WE# — Write enable |
| Pin G2 | ODT — On-die termination |
| Pin G3 | A0 — Address input 0 |
Safe Operating Area (SOA) & Thermal Characteristics
No official SOA curve available for this digital IC. Always operate within absolute maximum ratings specified in the datasheet. Ensure adequate cooling and derate as needed.
Typical Applications
IS43TR16256AL-107MBL is suitable for 6 applications: Networking Routers and Switches, Enterprise Storage Systems, Industrial PCs, Embedded Computing Platforms, Telecommunications Equipment, Consumer Electronics.
Networking Routers and Switches
The IS43TR16256AL-107MBL provides high-density, low-power memory for packet buffering and routing tables in networking equipment. Its 1866MT/s data rate ensures fast data throughput, while the 1.35V operation reduces power consumption in always-on infrastructure. The 96-TWBGA package fits compact line cards, and the wide temperature range supports reliable operation in telecom environments.
Recommended
Enterprise Storage Systems
In enterprise storage, the IS43TR16256AL-107MBL serves as cache or buffer memory, offering high bandwidth and low latency. Its 4Gb density and 256Mx16 organization enable efficient data caching, while the 1.35V supply minimizes power in large arrays. The device's auto-refresh and self-refresh modes support low-power standby, crucial for energy-efficient data centers.
Recommended
Industrial PCs
The IS43TR16256AL-107MBL is ideal for industrial PCs requiring robust memory in harsh environments. Its 0°C to +95°C case temperature range ensures reliable operation in factory floors, and the 1.35V low voltage reduces heat generation. The 96-TWBGA package provides excellent thermal performance, and the high data rate supports demanding industrial applications like machine vision and process control.
Recommended
Embedded Computing Platforms
For embedded systems, the IS43TR16256AL-107MBL offers a balance of density, speed, and power efficiency. Its 4Gb capacity supports complex applications like real-time data processing, while the 1.35V operation extends battery life in portable devices. The device's small footprint and surface-mount package simplify PCB design, and its compatibility with standard DDR3L controllers makes integration straightforward.
Recommended
Telecommunications Equipment
In telecom base stations and switches, the IS43TR16256AL-107MBL provides reliable memory for signal processing and protocol handling. Its high data rate and low power consumption are critical for 24/7 operation, and the wide temperature range ensures performance in outdoor enclosures. The 96-TWBGA package offers robust solder joints for vibration-prone environments.
Recommended
Consumer Electronics
The IS43TR16256AL-107MBL is suitable for high-end consumer devices like smart TVs and gaming consoles, where memory bandwidth and power efficiency are paramount. Its 1866MT/s data rate supports smooth 4K video playback, while the 1.35V supply reduces heat in slim enclosures. The device's small package enables compact designs, and its RoHS compliance meets global environmental standards.
Recommended
Recommended Products Summary
Engineering reference data for IS43TR16256AL-107MBL — comparison, design guidance, and compliance information.
Selection Guide
Comparison with Alternatives
| Parameter | This Product | IS43TR16256AL-107MBLI | IS43TR16256BL-107MBL | MT41K256M16HA-107G:E | K4B4G1646E-BYMATCV |
|---|---|---|---|---|---|
| Package | 96-TWBGA (9x13 mm) | 96-TWBGA (9x13 mm) | 96-TWBGA (9x13 mm) | 96-TWBGA (9x13 mm) | 96-TWBGA (9x13 mm) |
| Brand | ISSI | ISSI | ISSI | Micron Technology | Samsung Electronics |
| Memory Size | 4 Gbit | 4 Gbit | 4 Gbit | 4 Gbit | 4 Gbit |
| Organization | 256M x 16 | 256M x 16 | 256M x 16 | 256M x 16 | 256M x 16 |
| Supply Voltage | 1.35 V | 1.35 V | 1.35 V | 1.35 V | 1.35 V |
| Data Rate | 1866 MT/s | 1866 MT/s | 1866 MT/s | 1866 MT/s | 1866 MT/s |
| Operating Temperature | 0°C to +95°C | -40°C to +95°C | 0°C to +95°C | 0°C to +95°C | 0°C to +95°C |
| RoHS | Compliant | Compliant | Compliant | Compliant | Compliant |
Key Differentiators
- Industrial temperature grade option (vs IS43TR16256BL-107MBL)
- High data rate at low voltage (vs IS43TR16256AL-125KBL)
- Cross-brand availability (vs MT41K256M16HA-107G:E)
Design Notes
For DDR3L at 1866MT/s, maintain controlled impedance of 40-50 ohms for data lines and 50-60 ohms for address/command lines. Keep trace lengths matched within 100 mils to minimize skew. Use a solid ground plane beneath the memory device and place decoupling capacitors (0.1uF and 1uF) close to each VDD and VDDQ pin.
The IS43TR16256AL-107MBL requires a clean 1.35V supply. Use a dedicated voltage regulator with low output noise and fast transient response. Place a 10uF bulk capacitor and multiple 0.1uF ceramic capacitors near the VDD pins. Ensure the VDDQ supply is separate and well-filtered to prevent data corruption.
The device operates up to +95°C case temperature. In high-ambient environments, ensure adequate airflow or a heatsink. The 96-TWBGA package has a thermal resistance of approximately 20°C/W (theta_JA). For a 1W power dissipation, the junction temperature rise is 20°C, so keep ambient below 75°C to stay within limits.
Compliance Information
RoHS compliance confirmed from Mouser and ISSI datasheet. Other compliance data not provided.
